Intended use:
Unique design for Blood Banking use containing:
Blood Grouping, Blood typing, Cross Matching
Cell-washing, Blood coagulation, Cell separation,
Anti-Serum globulin test etc. Ideal use in hospital, clinics, laboratory center, education, veterinary and immunology testing. Etc.
| 3 preset modes: RPM/ RCF/TIME: | |
| Modes Speed RCF Time | |
| Mode 1 | 3104 rpm 1000 x g 60 seconds |
| Mode 2 | 2195 rpm 500 x g 60 seconds |
| Mode 3 | 3104 rpm 1000 x g 15 seconds |
| Code | PLC Series |
| Dimension | 26 x 26 x 26.5cm approx. |
| Control | Microprocessor controlled system |
| Rotor A-1205 | Fixed angle, 12 x 3 ~ 7 ml (12 x 75 mm) |
| Time preset | 60 /60 / 15 seconds for selection |
| Speed / RCF | 3 Preset RPM / RCF for selection |
| Safety shutout system | Option (shutout + Locking lid) |
| Drive Motor | Brushless, DC 12V |
| EMERGENCY STOP | Yes , emergency STOP |
| Power source | 100 V ~ 240VAC, 50/60Hz (or 12VDC) |
| Overheat protection | Yes, overheat protecting up to 105ºC |
| Standard accessory | 1. Tube adaptors, |
| 2. AC/DC switching adaptor, | |
| 3. Input 100 – 240VAC, 50/60Hz, 2.0A | |
| 4. Output: 12V, 6.67A, 80W | |
| Quality Standards | ISO 9001, ISO13485, GMP, CE, USFDA |
| Net weight | 8.0 kg or 17 .6 lbs. Approx. (±3%) |
