Features and Benefits
Hardware
- Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
- Security slot for optional Kensington-type lock and cable to help prevent theft
- Large, grade 304 stainless steel pan allows easy cleaning
- RS-232 interface is available to provide speedy connection to computers and printers
Software
- External calibration allows for verification and adjustment with weights
- Selectable digital filtering helps minimise effects of vibration and disturbances
- Security password control prevents unauthorised access
- Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
- Multilingual display allows use in many different countries
- Memory accumulation totals results
- Checkweighing with audible alarm
- Parts counting with preset sample sizes
Display
- High-resolution graphic display is amply sized for clear visibility
Power
- AC adapter included
Model | SAB 125i | SAB 225i | SAB 124e | SAB 224e | SAB 314e | SAB 124i | SAB 224i | SAB 314i | SAB 414i | SAB 514i | |
Capacity | 62g / 120g | 82g / 220g | 120g | 220g | 310g | 120g | 220g | 310g | 410g | 510g | |
Readability | 0.01mg/ 0.1mg | 0.01mg/ 0.1mg | 0.0001g | 0.0001g | 0.0001g | 0.0001g | 0.0001g | 0.0001g | 0.0001g | 0.0001g | |
Repeatability | 0.02mg/ 0.1mg | 0.02mg/ 0.1mg | 0.0002g | 0.0002g | 0.0002g | 0.0002g | 0.0002g | 0.0002g | 0.0002g | 0.0002g | |
Weighing Units | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | g, mg, lb, oz, ct, GN, dwt, mm, ozt, T, tl.H, tl.S, tl.T, custom unit | |
Calibration | Internal automatic calibration | Internal automatic calibration | External calibration | External calibration | External calibration | Internal automatic calibration | Internal automatic calibration | Internal automatic calibration | Internal automatic calibration | Internal automatic calibration | |
Stabilisation Time | 6 | 6 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | |
Pan Size | 80mm ø | 80mm ø | 80mm ø | 80mm ø | 80mm ø | 80mm ø | 80mm ø | 80mm ø | 80mm ø | 80mm ø | |
Linearity | 0.1mg / 0.2mg | 0.1mg / 0.2mg | 0.0003g | 0.0003g | 0.0003g | 0.0003g | 0.0003g | 0.0003g | 0.0003g | 0.0003g | |
Power Supply | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | 24V 50/60Hz 500mA adapter | |
Construction | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | |
Interface | RS-232 | RS-232 | RS-232 | RS-232 | RS-232 | RS-232 | RS-232 | RS-232 | RS-232 | RS-232 | |
Operating Temperature | 10° to 30°C | 10° to 30°C | 10° to 30°C | 10° to 30°C | 10° to 30°C | 10° to 30°C | 10° to 30°C | 10° to 30°C | 10° to 30°C | 10° to 30°C | |
Net Weight | 7kg | 7kg | 6.7kg | 6.7kg | 6.7kg | 7kg | 7kg | 7kg | 7kg | 7kg | |
Dimensions Overall | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | 224x374x338mm (wxdxh) | |
Display Digit Height | 15mm | 15mm | 15mm | 15mm | 15mm | 15mm | 15mm | 15mm | 15mm | 15mm |
